Quincy 3-Phase 60-Gallon Rotary Screw Air Compressor w/ Dryer
Quincy 4152051914 QGS 5-HP 60-Gallon Rotary Screw Air Compressor w/ Dryer (208-230/460V 3-Phase)
The Quincy QGS 5-HP rotary screw air compressor with integrated dryer delivers quiet, efficient, and reliable compressed air for demanding operations. Its oil-injected twin screw pump ensures consistent performance with minimal vibration compared to traditional piston compressors. Designed for continuous 100% duty cycle operation, this unit keeps your applications running smoothly around the clock.
Equipped with an integrated refrigerated air dryer, it effectively removes moisture, dirt, and oil from the air, protecting downstream tools and systems. Premium synthetic lubrication provides up to 8,000 hours of runtime with low oil carryover, while the start/stop control system and TEFC electric motor offer dependable functionality in varied work environments. The quiet enclosure maintains noise levels at only 62 dBA, reducing fatigue and enhancing workplace comfort.
For warranty information please see the below link.
Product Features
- Superior Compressed Air Turn-Key Performance
- ntegrated Refrigerated Air Dryer
- Continuous 100% Duty Cycle
- Standard Quiet Enclosure
- Premium Synthetic Lubrication
- Start/Stop Operation
- Long Life V-Belt Drive
- TEFC Electric Motor
- Extended 3 Year Factory Warranty Available
- True Blue 5-Year Warranty with Quincy Authorized Start Up
Product Specifications
General Information
| Product Category | Air Compressor - Stationary |
Motor
| Voltage | 208-230/460 Volt AC |
| Phase | Three Phase |
| dBA | 62 |
| Amp Draw | 28 |
| Recommended Breaker | 60 Amp Breaker |
Engine
| HP | 5 |
| Engine Low Oil Shut-off | Yes |
Pump
| CFM | 15.6 |
| CFM Rated @ | 150 PSI |
| Max PSI | 150 PSI |
| Oil Sight Glass | Yes |
| Pump Type | Rotary |
| After Cooler | No |
| Pump Drive | Belt Drive |
| Oil Type | Oil Lubricated |
| Pump Low Oil Shut-off | Yes |
| Duty Cycle | 100% |
Tank
| Tank Size | 60 Gallons |
| Tank Included | Yes |
| Tank Outlet | 1/2 Inch |
| Electronic Drain Valve | No |
| Tank Orientation | Horizontal |
Accessories
| Air Dryer | Yes |
| Air Filter | Yes |
Overview
| Weight | 543 Pounds |
| Certification | ASME |
| Consumer Warranty | 1 Year |
| Commercial Warranty | 1 Year |
| Product Length | 56 Inches |
| Product Width | 23 Inches |
| Product Height | 51 Inches |
| Power Type | Electric |
Downloads
Brochure
Manual
Warranty
