Katool KT-C9372 Brake Lathe Machine

$5,559.00 $6,699.00
Shipping FAQ's

Product Description

Katool C9372 Brake Lathe Machine

The Katool C9372 Combination Disc and Drum Brake Lathe is a powerful and versatile piece of automotive equipment, engineered to meet the demands of busy mechanic shops and professional brake service facilities. This heavy-duty lathe handles a wide range of rotor diameters from 4" to 20" and drum diameters from 6" to 19.5", making it suitable for diverse vehicle maintenance needs.

Its infinitely adjustable feed rates offer precise control over cutting speeds, ensuring a high-quality finish whether performing rough cuts or fine resurfacing. The quick changeover design streamlines operations by allowing rapid transitions between rotor and drum machining tasks. An automatic stop function enhances operator safety by halting the machine after cutting.

Product Features

  • Versatile Machining Capabilities: Accommodates rotor diameters from 4" to 20" (102-508mm) and drum diameters from 6" to 19.5" (152-500mm), allowing for a broad range of applications.
  • Adjustable Feed Rates: Infinitely adjustable feed rates enable precise control over cutting speeds, ensuring optimal finish quality for both rough cuts and fine finishes.
  • Quick Changeover Design: A convenient design allows for rapid transitions between rotor and drum machining, enhancing operational efficiency.
  • Automatic Stop Function: Features an automatic stop position after cutting, promoting safety and streamlining workflow.
  • Comprehensive Adapter Package: Includes a fully equipped adapter package to accommodate various brake components, expanding service capabilities.

Product Specifications

Rotor Diameter 4”-20” (102-508mm)
Maximum Rotor Thickness 2.85” (73mm)
Drum Diameter 6”-19.5” (152-500mm)
Drum Depth 6.5” (165mm)
Flywheel Diameter 6”-24” (152-610mm)
Spindle Weight Capacity (Standard 1” Arbor) 150 lbs (68 Kg)
Spindle Speed 70-320 RPM
Feed rates - Rotor and Drum 0”-0.026” (0mm-0.66mm)
Feed Rates Per Minute 2.54” (64.5mm)
Shipping Weight 661.3 lbs / 300 KG
Motor 110V/220V 50/60HZ
Dimensions 43.3 x 28.7 x 28.3 inches / 1100 x 730 x 720mm
